DOT-6400 : Water Quality Sensors |
|
|
 |
Parameter |
: DO |
|
Range |
: 0 to 20 ppm |
|
Display |
: Nil |
|
Accuracy |
: ± 0.5% / 1.0% of F.S |
|
Power Supply |
: 24V AC |
|
Max Pressures |
: Upto 7 Bar |
|
| |
| Special Features |
|
|
Large solution capacity for long term deployment |
|
Models with and without temperature sensor |
|
Easy installation and maintenance |
|
mV or 4-20mA output models available |
|
| |
| Application |
|
| The DO6400 & 7400 series dissolved oxygen sensors feature a large capacity electrolyte holder, positive fit, easy to replace membrane and dependable galvanic cell technology for long term deployment. The body design ensures a good grip
when wet. Ideal for Aquaculture and wastewater monitoring
applications, these sensors require minimal maintenance.
PTFE or High-Density Polyethylene (HDPE) membranes are
available.2 Replacement membranes,installation tool and
electrolyte are included. Additonal maintennace parts are in
convenient kits (see ordering information). Sensors with mV
output as well as built-in 4-20mA output in 0-100% and
0-200% saturation range are available. |
|
| |
| Specifications |
|
| O2Measuring Range |
: |
DO6400, DO6400TC (0.520ppm), DO6441(0100%),
DO6442(0-200%) |
| |
|
DO7400, DO7400TC (0.03-20ppm),
DO7441 (0100%), DO7442(0-200%) |
| Body Material |
: |
Noryl |
| Cathode |
: |
Silver |
| Anode |
: |
Zinc (DO6400 Series), Lead (DO7400 Series) |
| Maximum Temperature |
: |
50 Degrees C |
| Power Requirement |
: |
12-36V DC (for models DO6441,DO6442,DO7441
and DO7442 only ) |
| Temperature Sensor |
: |
(User specified temperature elements) Connect to your controller or PLC for temperature output |
| Cable length |
: |
10 feet, tinned leads |
| Minimum Flow rate |
: |
2 inches per second |
| Output @ Air Saturation |
: |
HDPE DO6400 & DO7400 (45mV +/- 9mV) |
| |
|
PTFE DO6400 & DO7400 (33mV +/- 9mV) |
| |
|
|
| |
|
HDPE & PTFE DO6441, DO7441(0-100%) - fixed 4 - 4.5mA = <1 ppm DO |
| |
|
HDPE & PTFE DO6441, DO7441 (0-100%)- fixed 18-22 mA = saturated air |
| |
|
|
| |
|
HDPE & PTFE DO6442- fixed 4 - 4.5mA = <1 ppm DO
HDPE & PTFE DO6442- fixed 11-13 mA = saturated air |
|
| |
|
|
|
|
|
