Model |
: PGMG |
|
Type |
: Test Gauge |
|
Dial Size |
: 6", 10" |
|
Range |
: -760mmHg to 1000 bar |
|
Wetted Parts |
: Copper Berryllium |
|
Case |
: SS304 |
|
| |
| Special Features |
|
|
High precision measuring system |
|
High resolution dial |
|
Anti parallax mirror |
|
Socket & case welded construction |
|
Stainless steel case |
|
Standard followed in general en 837-1 |
|
| |
| Applications |
|
| Calibration /Testing In Laboratory Fits At Various Process Industries. |
|
| |
| Specifications |
|
| Standard Version: 150mm, 200mm, 250mm |
|
Accuracy |
: ±0.25% of F.S. |
|
Ambient temperature |
: upto 65°C |
|
Process temperature |
: + 65°C |
|
Operating Pressure |
: 75% of the Scale Value |
|
| |
|
Case |
: AISI 304 SS |
|
Ring |
: AISI 304 SS (Bayonet Type) |
|
Bourdon |
: Beryllium Copper |
|
Socket |
: AISI 31 6L SS |
|
Movement |
: High Precision Jewel Bearing Type |
|
| |
|
Protection |
: IP 65 |
|
Dial |
: Aluminium, Green with Black Marking & Anti
parallax Mirror Band |
|
Pointer |
: Balanced, Knife-Edge Micrometer Adjustable |
|
Pointer Stopper |
: Spring Type |
|
Gasket |
: Neoprene |
|
Welding |
: Alloy Brazing |
|
Window |
: Shatter proof / Safety Glass |
|
Blow Off Disc |
: Neoprene |
|
Carrying Case |
: Wooden carrying case |
|
Calibration certificate |
: 5 Point traceable calibration certificate |
|
| |
| All Stainless Steel Test Gauge (Option - YQ) |
|
Accuracy |
: ± 0.5% OF F.S. |
|
Ambient temperature |
: -25°CTO+65°C |
|
Process temperature |
: + 150°C |
|
Bourdon |
: AISI316LSS |
|
Socket |
: AISI 31 6 L SS |
|
Movement |
: AISI 304 SS |
|
Welding |
: Tig Argon Arc Welding |
|
