PD6800 : OEM Pressure Transmitter With Display |
|
|
 |
Model |
: PD6800 |
|
Type |
: With Display |
|
Range |
: -1 to 2000 bar |
|
Output |
: 4 - 20mA, 0 to 5V, 0.5 to 4.5V, 1 to 5 V, 0 - 10V |
|
Accuracy |
: ± 0.25% of F.S |
|
Temperature Limits |
: -25 to 85ºC |
|
Over Pressure |
: 2X |
|
| |
| Description |
|
| PD68 Series (LED local display) Adopting global advanced electron ceramic technology, no any medium liquid in the sensor chip , has the character of overload resistance, high impact resistance, excellent linearity, lasting high stability, wide temperature range, corrosion proof, etc. |
|
| |
| Applications |
|
| This series can be applied in hydraulic machinery , Building Automation System , constant pressure water supply , machine loading fluid in automatization fields, pressure measure and control. |
|
| |
| Specifications |
|
|
Pressure range |
: 0~0.1MPa~200MPa |
|
Over load |
: 150%FS |
|
Burst pressure |
: 300%FS |
|
Output |
: 4-20mA |
|
Power supply |
: 12-36VDC |
|
Response time |
<5ms |
|
Combine error |
: 0.25%FS; 0.5% FSO
(Including Linearity, Repeatability &
Hysteresis) |
|
Repeatability |
: s= + 0.2%FSO |
|
Long term stability |
: s= ± 0.2%FS/year |
|
Pressure connection |
: M20x 1.5, G1/2, G1/4, 1/2NPT
(customer tailor) |
|
Operating temperature |
: -20^-80^ |
|
Temperature compensation |
: -2O'C~65'C |
|
Electrical connector |
: Hirschman DIN43650 IP65 |
|
|
|
|
|
| |
|
