PGH : Homogenizer Gauge |
|
|
 |
Model |
: PGH |
|
Type |
: Homogenizer |
|
Dial Size |
: 4" |
|
Range |
: 0 - 160 / 1000 bar |
|
Wetted Parts |
: SS316 |
|
Case |
: SS304 |
|
| |
| Special Features |
|
|
Fillable version facilitate usage in vibration zones to avoid damages to its mechanism. |
|
Suitable to use in dairy homogenizer machines. |
|
| |
| Applications |
|
| These gauges are being used in applications where hygiene is of prime importance like Dairy Food, Beverages & Pharmaceutical Industries. |
|
| |
| Specifications |
|
| Standard Version: 100mm100mm, 150mm |
|
Accuracy |
: ±1.6% of F.S. |
|
Ambient temperature |
: - 25°C to + 65°C |
|
Process temperature |
: Max. 120°C |
|
Operating pressure |
: 75% of the Scale Value |
|
| |
|
Case |
: AISI 304 SS |
|
Ring |
: AISI 304 SS, Bayonet Type |
|
Bourdon |
: AISI 316 LSS |
|
Socket |
: AISI 316 LSS |
|
Movement |
: AISI 304 SS |
|
Diaphragm |
: AISI316LSS |
|
Body |
: AISI 316 SS |
|
Joints |
: Tig Argon Arc Welding |
|
| |
|
Protection |
: IP 65 |
|
Dial |
: Aluminium, black graduation on white
background |
|
Pointer |
: Aluminium, black coloured micrometer zero
adjustable |
|
Window |
: Plexi Glass |
|
Blow off Disc |
: Neoprene |
|
Gasket |
: Neoprene |
|
Sealing liquid |
: Food grade oil |
|
Dampening Liquid |
: Glycerine 98% |
|
|
|
|
|
| |
|
