TGSS : Bimetallic Temperature Gauge |
|
|
 |
Type |
: Bimetallic |
|
Dial Size |
: 2.5" - 6" |
|
Range |
: -50 to 600°C |
|
Wetted Parts |
: SS316 |
|
Case |
: SS304 |
|
Capillary |
: NIL |
|
| |
| Special Features |
|
|
Stainless steel case & stem |
|
Bottom / Back / Every Angle Entry |
|
Standard Followed: EN 13190 |
|
| |
| Applications |
|
| Food & beverage, pharmaceutical, cryogenics, chemical & petrochemical industries, conventional & nuclear power Plants, pumps, hydro-cleaning machines, presses, engine Compressors, turbines, diesel engines & refrigerating plants. |
|
| |
| Specifications |
|
| Standard Version: 63mm, 100mm, 150mm |
|
Accuracy |
: Class 1 as per EN 13190 |
|
Ambient temperature |
: - 25 oC to + 65 oC |
|
Process pressure |
: 15 kg/cm2 (Without Thermowell) |
 |
Over Range Limit |
: 115% of the Scale Value or 600 oC, whichever
is minimum |
|
Stem Diameter |
: 6mm / 8mm / 10mm / 12mm |
|
Stem Length |
Refer Scale Table |
|
| |
|
Case |
: AISI 304 SS |
|
Ring |
: AISI 304 SS, Bayonet Lock |
|
Stem |
: AISI 316 SS |
|
Connecion |
: AISI 316 SS |
|
Sensing Element |
: Bi-metal strip coiled |
|
Joints |
: Tig Argon Arc Welding |
|
| |
|
Protection |
: IP 65 |
|
Dial |
: Aluminium, black graduation on white
background |
|
Pointer |
: Aluminium, black coloured fixed pointer |
|
Window |
: Sheet Glass |
|
Gasket |
: Neoprene |
|
|
|
|
|
| |
|
