SY2 : Coil Type Syphon |
|
|
 |
Type |
: Syphon |
|
Model |
: SY2 |
|
MOC |
: SS316 / CS |
|
Max Temp |
: 150°C |
|
Max Pressure |
: 70 Bar |
|
Size |
: 1/8" - 1" |
|
| |
| Special Features |
|
| Siphons are used mainly to protect pressure instruments, gauges, Switches and transmitters directly coming in Contact with high temperature process fluids or vapours. Filled with Condensation fluids, these are mounted Between process and pressure instrument. They reduce process Pulsation, act as heat dispenser and generate cooling effect to save Instrument from working at dangerous temperature. |
|
| |
| Specifications |
|
|
Material |
: AISI 316 Stainless Steel |
|
Pipe Size |
: Schedule 40 |
|
Operating Pressure |
|
Carbon Steel |
: 150 kg/cm2at 430 "Cmax. |
|
Stainless Steel |
: 135 kg/cm2 at 450 °C max. |
|
|
|
|
|
| |
|
