SCS : Compact Diaphragm Seal |
|
|
 |
Type |
: Compact Seal |
|
Range |
: -1 to 400 bar |
|
Connection |
: Threaded |
|
Fill Fluid |
: Silicon / Fluorolube |
|
Wetted Parts |
: SS316L / Exotic |
|
Non Wetted Parts |
: SS316 |
|
| |
| Special Features |
|
|
| |
| Applications |
|
| Diaphragm seals are provided in the instruments like pressure gauges, switches, transmitters in order to isolate the sensing element from the main service due to its corrosive, viscous and sedimented nature and to avoid clogging and solidification. |
|
| |
| Specifications |
|
| Standard Version: Suitable for NS upto 63mm |
|
Range |
: -1 kg/cm2 to 21 kg/cm2 |
|
Process temperature |
: - 40°C to 200°C or as per fill fluid |
|
Instrument Connection |
: 1 /4" BSP(F) |
|
Process Connection |
: 1/4” BSP (M) |
|
| |
|
Diaphragm |
: AISI 316LSS |
|
Body |
: AISI 316SS |
|
Fill Fluid |
: Silicon Oil - DC 200 |
|
|
|
|
|
| |
|
