NV1 : Needle Valve |
|
|
 |
Model |
: Needle Valve |
|
MOC |
: AISI SS316 / AISI SS304 / Exotic Material |
|
Temp Lmiit |
: 250°C |
|
Pressure Limit |
: 15000 psi |
|
No. of Valves |
: 1 |
|
Design |
: R Type |
|
| |
| Description |
|
| Type needle valves with hard seat are designed for use on applications requiring complete isolation or throttling of the media.the conical metal tip (stem type ct) press fitted ensures perfect alignment for positive bubble tight shut-off. Available with end connections in sizes from 1/8" to 1" and a wide choice in connections of female screwed, male screwed, male to female screwed or socket weld. |
|
| |
| Applications |
|
|
High Pressure Line Shut Off. |
|
Instrument Isolation. |
|
Gauge Isolation. |
|
Drain Valve. |
|
Liquid And Vapor Service |
|
| |
| Specifications |
|
|
Pressure |
: 400 bar |
|
Max Temp. |
: 240°C |
|
Material |
: Stainless Steel |
|
Stem |
: (CT) chrome plated Conical tip press
fitted hard . |
|
Gland Packing |
: PTFE (Grafoil to be used for
temperature above 240°C till
550°C) |
|
Stem Packing Area |
: Burnished mirror finish for Smooth
valve operation. |
|
Safety |
: Back seating for preventing stem
blowout. |
|
|
|
|
|
| |
|
