ML8Y : Ultrasonic Level Switch |
|
|
 |
Type |
: Ultrasonic |
|
MOC |
: Non-Contact |
|
Range |
: Upto 40m |
|
Contacts |
: 4 - 20 mA; 2 SPDT |
|
Enclosure |
: IP67 |
|
Max Pressure |
: Upto 10 bar |
|
| |
| Features & Benefits |
|
|
Provides two-wire 4-20 mA analog output |
|
Replaces capacitive rods, bubbler systems and sight gages |
|
Compact sensor with 2” deadband and beam width |
|
| |
| Description |
|
| This general purpose, ultrasonic sensor provides non-contact level measurement up to 1500” (40 m) with a 4-20 mA output. This device directly replaces contact measurement sensors connected to a PLC analog input card for easy design conversion or field retrofit. The two-wire, 4-20 mA output is ideal for longer signal distances up to 1000’. The sensor is well suited for a wide range of corrosive, sticky or dirty type media. ML8Y Tx is broadly selected for small atmospheric tank, IBC, drum, skid or process vessel and sump applications. |
|
| |
| Specifications |
|
|
Range |
: 1500” (40 m) |
|
Accuracy |
: 0.5% |
|
Resolution |
: 0.01m |
|
Beam Width |
: 4” (10 cm) |
|
Deadband |
: 4” (10 cm) |
|
Supply Voltage |
24 VDC (loop) |
|
Loop Resistance |
: 400Ω Max @ 24 VDC |
|
Consumption |
: 0.5W |
|
Signal Output |
: 4-20mA, Two-Wire, |
|
Contact Type |
: 2 SPDT Optional |
|
Loop Fail-Safety |
: 4 mA, 20 mA, 21 mA, 22 mA or Hold Last |
|
Configuration |
: 3 Buttons |
|
Temp. Compensation |
: Automatic over range |
|
Process Temperature |
: F: 20° to 140° C: -7° to 60 ° |
|
Ambient Temperature |
: F: -31° to 140° C: -35° to 60° |
|
Max. Working Pressure |
: 15 PSI |
|
Enclosure |
: Type 6P, Encapsulated, Corrosion Resistant |
|
Enclosure Material |
: PC/ABS FR |
|
Strain Relief Material |
: Santoprene |
|
Transmitter Material |
: PVDF |
|
Cable Length |
: 48” (Opt ional) |
|
Cable Jacket Material |
: Polyurethane |
|
Process Mount |
: 2” with Che ck Nut |
|
Mounting Gasket |
: Viton® |
|
Classification |
: General Purpose |
|
Approvals |
: CE |
|
Warranty |
: 12 Months |
|
|
|
|
|
| |
|
