LSTL : Tilt Level Switch |
|
|
 |
Type |
: Tilt Level |
|
MOC |
: SS316 |
|
Range |
: Upto 10m |
|
Contacts |
: 1 SPDT |
|
Enclosure |
: Ex / IP65 |
|
Max Pressure |
: Upto 10 bar |
|
| |
| Special Features |
|
|
Reliable, robust, compact, energy saving & easy to install |
|
Omni directional - can operate in any direction |
|
ATEX certified for hazardous area |
|
Float protection index IP68 or IP 6X assuring maximum dust protection |
|
Welded / vulcanized floats (not glued/crimped) to suit most aggressive conditions w/o being punctured / damaged |
|
High quality neoprene/hypalon cable complying with NFC 32-102-16/HO7RN8-F, retains flexibility over time w/o hardening as compared to PVC cables |
|
| |
| Application |
| Tilt Level Detectors for Solids are designed for detection of high level in silos / chutes & presence of material on conveyor belts. The switch consists of a 3-core cable in different lengths, carrying an integral cone at one end. The cone contains a microswitch internally, which operates when the cone
is tilte in any direction from its normal vertical position |
| |
| Specifications |
|
|
Tilt (diff angle) |
: +/- 10° |
|
Max Temperature |
: 85°C |
|
Float protection |
: IP 68 |
|
Contact rating |
: 20A(R)-8A(I),250VAC |
|
Cable |
Neoprene H07RN8-F |
|
Cable type |
3 conductors x 1 mm² |
|
Float size |
Ø95mm X 152mm ht |
|
Biconical shell |
Copolymer PP |
|
Cone weight w/o cable |
462 gms |
|
Cable weight |
115 gm/meter |
|
Area classification |
Non explosive |
|
Std cable lengths (mtrs) |
5, 6, 10, 13, 15, 20 & 30 |
|
|
|
|
|
| |
|
